mcr WIP LD
multi blade smoke control damper
The mcr WIP LD smoke dampers are intended for installation in manually or automatically operated fire ventilation systems. The devices are used in fire ventilation systems or in mixed fire and comfort ventilation systems (smoke evacuation or air supply systems).
The mcr WIP LD is Certified and fully compliant with EN-12101-8
mcr WIP LD comes complete with steel grille painted RAL 9010.
Stock Sizes (structural opening sizes):
800mm wide x 1900mm high = 1.03m2
800mm wide x 1200mm high = 0.63m2
FREE AREA
Multi-blade smoke damper mcr WIP LD:
Electric control: 24 V / 1 x 0.8 A
Damper casing: 350mm deep
Manufactured from galvanised steel sheet
Galvanised steel damper blades (no infill)
1.03m2 and 0.63m2 to meet Natural and Mechanical Shaft requirements
Classification: EN 12101-8
BIM models: Y
Damper casing Black, Grille White RAL 9010 as standard.
